-X BAG0235.4 01.23
6.1.1.7 Table
Actual value according to
calculation
cording to tractor
operator’s manual
load capacity (two
tires)
Minimum ballast front /
rear
lb
[kg]
-- --
Total weight
lb
[kg]
≤
lb
[kg]
--
Front axle load
lb
[kg]
≤
lb
[kg]
≤
lb
[kg]
Rear axle load
lb
[kg]
≤
lb
[kg]
≤
lb
[kg]
• You can find the approved values for the total tractor weight,
axle loads and load capacities in the tractor registration papers.
• The actual calculated values must be less than or equal to (≤ )
the permitted values!
WARNING
Risk of contusions, cutting, catching, drawing in and being
knocked down through insufficient stability and insufficient trac-
tor steering and/or brake power.
It is prohibited to connect the implement to the tractor used as the
basis for calculation if:
•
one of the actual, calculated values is greater than the approved
value
•
there is no front weight (if required) attached to the tractor for the
minimum front ballast (G
V min
).
• Ballast your tractor with weights at the front or rear if the tractor
axle load is exceeded on only one axle.
• Special cases:
ο If you do not achieve the minimum ballast at the front
(GV min) from the weight of the front-mounted implement
(GV), you must use ballast weights in addition to the front-
mounted implement.
ο If you do not achieve the minimum ballast at the rear
(GH min) from the weight of the rear-mounted implement
(GH), you must use ballast weights in addition to the rear-
mounted implement.
