Amazone ZA-X - Calibration Kit (Optional)

Structure and function
52
ZA-X BAG0235.4
01.23
5.13 Calibration kit (optional)
The calibration kit is used to determine the slider
position for the desired spread rate using a nom-
ogram.
Installing:
1. Remove the plastic plug (Fig. 41/1).
2. Mount the outlet chute (Fig. 42/1) using the
fastening screws (Fig. 42/2).
Fig.
41
Fig.
42
