PN 305200901, Rev YT
• Power Requirements
The analyzer operates on 24 VDC. If 24 VDC is not available, a standalone
24 VDC power supply (PN305442901) with universal input (85–265 V,
47–63 Hz) can be purchased from AMETEK. If the analyzer is powered by
a 24 VDC source other than that supplied by AMETEK, the power source’s
output must be isolated from hazardous mains voltages by use of double
or reinforced insulation having a minimum dielectric strength of 2300 VAC.
• System Tubing
Recommended system tubing is 1/8-inch OD, 316 stainless steel, electro-
polished, meeting ASTM #632 specications (AMETEK PN 257707000 or
better). For low-level (<20 PPMV) measurements 1/8-inch OD, 316L VAR
stainless steel tubing with a nish of 10RA (or less) is highly recommended.
• Dry Reference Gas
An external Dryer (AMETEK Dryer PN 305400901S or equivalent) is required
to dry Reference gas to less than 0.025 PPMV.
Dryers must be periodically replaced. In normal use, the AMETEK Dryer
should dry a 50 PPM Reference gas to specication for one (1) year.
Unpacking and Inspecting the Equipment
Remove any packing material from the 3050-OLV Moisture Analyzer shipping
crate. Check for damage. If equipment is damaged, notify the carrier and con-
tact AMETEK Service (https://www.ametekpi.com/customersupport/request-
support) immediately if parts are missing or damage is found, and to verify if
damaged parts will require replacement prior to safely installing and operating
the analyzer/equipment.
Installation and Start-Up | 2-3
