PN 305200901, Rev YT
Dryer Installation Instructions
Tools needed to install Dryer:
• One #2 slotted screwdriver
• Two 7/16-inch wrenches
• One 5/8-inch wrench
• One 3/4-inch wrench
1. To alleviate stress on the tube connections attach the Dryer to the Dryer
Bracket using two (2) 10-32 screws, and at and lock washers (Figure 2-4).
2. Install adapter tubes onto the analyzer.
a. Remove plastic dust caps from the Dryer input and output on the ana-
lyzer.
b. Remove compression nuts and verify ferrule is properly installed.
c. Reinstall nuts to nger tight.
d. Insert adapter tubes through female compression nuts and ferrules
until they bottom out.
e. Using two (2) 7/16-inch wrenches (one to hold the bulkhead tting),
swage the compression ttings into the bulkhead ttings on the analyz-
er. For proper installation, the tting should be 1/4-turn past nger-tight.
3. Attach the Dryer to adapter tubes:
Do not leave the Dryers open to ambient air. The high moisture levels
present in ambient air can damage or shorten the life span of these
components. Make Dryer connections promptly.
a. Remove female VCR nuts from Dryer VCR glands.
b. Verify VCR gaskets are in place.
c. Align adapter tubs with Dryer VCR glands.
d. Slide female nuts over VCR adapters and screw nuts onto Dryer glands.
Secure VCR nut behind VCR adapter on the Dryer with 5/8-inch wrench.
Use a 3/4-inch wrench to tighten nuts 1/8-turn past nger-tight.
e. Check for leaks.
Installation and Start-Up | 2-9
