PN 305200901, Rev YT
Specications
Specications included in this chapter are typical for the ranges listed.
For custom ranges/applications, or consult with your AMETEK repre-
sentative.
3050-OLV Moisture Analyzer Specications
Specication Description
Ranges Calibrated 0.1–2,500 parts per million by volume (PPMV)
Readings can also be displayed in units of PPMW, lb/mmscf,
mg/Nm
3
, and dewpoint (requires process pressure input)
Accuracy ±10 % of reading or ±0.1 PPMV, whichever is greater.
Repeatability ±5 % of reading or ±0.05 PPMV, whichever is greater.
Reproducibility ±10 % of reading from 1–100 PPMV or ±0.05 PPMV, whichever is
greater.
Limit of Detection 0.1 PPMV when used with 3050-OLV Dryer
Response Time 63 % to a step change in less than three (3) minutes.
95 % to a step change in less than ve (5) minutes.
Sensitivity ±5 % of reading or ±0.05 PPMV, whichever is greater.
Allowable Inlet Pressure
Range
1.38–3.45 BARG
Exhaust Pressure 0–1.03 BARG
Sample Gas Temperature 0 °C to 100 °C (32 °F to 212 °F)
Gas Flow Requirements Sample: 150 ±20 SCCM
Bypass: 1 ±0.1 SLPM
Outputs Isolated 4–20 mA (software congurable; 12 bit resolution),
100–500 Ω load required.
RS-232 or RS-485, 2- and 4-wire mode.
Alarms Concentration Alarm
Data Valid
System Alarm
All contacts hermetically sealed reed type (30 VAC maximum,
60VDC maximum, 50 VA maximum, Resistive)
Environmental Ambient Temperature:
Base Analyzer: 5° to 50 °C (41° to 122 °F)
Zone 1/Division 1 IP65 and Division 2 NEMA-4X Analyzer:
-20° to 50 °C (-4° to 113 °F)
Maximum Altitude: 2000 meters
Relative Humidity: Up to 90 %, non-condensing
Pollution Degree 2
Installation Category II
Specications | 5-1
