Sensor Saver
Select this check box to enable Sensor Saver.
Checked Analyzer operates with a slow cycle time, maxi-
mizing Measuring Cell life at the expense of
system response time.
Not Checked Analyzer operates with a rapid cycle time, mini-
mizing system response time.
Gas Saver
Select this check box to enable Gas Saver.
Checked Analyzer runs on a sample ow rate of 150
SCCM.
Not Checked Analyzer uses an internal bypass, which in-
creases the response speed of the system.
Provides sample ow rate >1 SLPM.
4–20 mA Output
Set up your analog output range.
20 mA Enter your high analog output limit.
4 mA Enter your low analog output limit.
Hold during verify Check this box to hold analyzer output during
the Verication.
Alarm Output
Select this check box to set up the limits for the Concentration Alarm.
Enable Check this box to enable the Concentration
Alarm.
High Limit Enter the high limit for the Concentration
Alarm.
Low Limit Enter the low limit for the Concentration Alarm.
Saving the Settings on the Setup Tab
To save settings on the Setup tab, click Apply.
PN 305200901, Rev YT
Controller/Interface | 3-13
