Test mA Output
The Test mA Output buttons allow you to test the analog outputs. Use a
meter while testing the outputs. Refer to Figure 2-6 for wiring.
To exit out of Test mode, click another button. Test mode will automati-
cally time out after 10 minutes of inactivity.
When the analyzer switches from Test mode to Online, the analyzer
resets itself.
