5-10 :Trace Subsystem VNA Commands
5-56 PN: 10580-00319 Rev. N S412E PM
ACTIVE_TRACE Current active trace. Where:
0 is for trace 1, 1 for trace 2, 2 for trace 3, and
3for trace4
TOTAL_TRACE Total number of traces
AVERAGING_COUNT Current Averaging Count
AVERAGING_FACTOR Averaging factor
EXTERNAL_REFERENCE External Reference where 0 is for Off and 1 is for
Locked
EXT_REF_FREQ_LIST Currently not being used.
SWEEP_TYPE Sweep type. Available sweep types are:
Single = 0 and Continuous = 1
EXTERNAL_TRIGGER Currently not being used.
BIAS_TEE_STATE Bias Tee State. Currently available Bias Tee
states are:
Off = 0 and Internal = 2
BIAS_TEE_PORT_SELECTION Bias Tee port selection. Where:
1 is port 2.
BIAS_TEE_VOLTAGE_Px Internal Bias Tee voltage, where:
x is the port number.
Return value is 1000 times the current voltage
value in Volts.
INT_BIAS_TEE_VOLTAGE Internal Bias Tee voltage. Return value in mV.
Internal Bias Tee current limit, where:
x is the port number.
Return value is in mA.
BIAS_TEE_CURRENT_LIMIT_Px Internal Bias Tee current limit, where:
x is the port number.
Return value is in mA.
INT_BIAS_TEE_CURRENT Internal Bias Tee current. Return value is in mA.
RF_SOURCE_POWER Source Power. Current valid source power:
low = 0, and high = 1.
CABLE The index of the selected cable list, where 0 is the
first in the list.
DIST_UNITS Distance units. Available distance units are:
Meter = 0, Feet = 1
Table 5-3. Trace Header Parameters (Sheet 3 of 8)
Parameter Name Description
