7-10 :TRACe Subsystem Fixed WiMAX Commands
7-22 PN: 10580-00319 Rev. N S412E PM
7-10 :TRACe Subsystem
This subsystem contains commands related to the transfer of trace data to and from the
instrument.
:TRACe:PREamble? <trace type>
Title: Returns trace header information for the specified trace. The <trace
type> must be one of the following:
SPECtrum|PVTime|ACPR|CONStln|SFLatness|EVSCarrier|EVSY
mbol
Data can be transferred to and from the 7 available display trace types.
Use the commands in the MMEMory subsystem to store and recall
traces from the instrument memory. The response begins with an
ASCII header. The header specifies the number of following bytes. It
looks like #AX, where A is the number of digits in X and X is the
number of bytes that follow the header. Parameters are returned in
comma-delimited ASCII format. Each parameter is returned as
“NAME=VALUE[ UNITS],” Valid parameter names are shown in
Table 7-1, “Available Parameters in WiMAX and Mobile WiMAX Mode”
on page 7-22.
Parameter: <trace type>
Related Command: :TRACe:DATA?
WiMAX, Mobile WiMAX Parameter Names
Table 7-1. Available Parameters in WiMAX and Mobile WiMAX Mode (Sheet 1 of 3)
Parameter Name Description
SN Instrument serial #
UNIT_NAME Instrument name
TYPE The data type (Setup or Data)
DESCR Trace name
DATE Trace date/time
BASE_VER Base FW version
APP_NAME Application name
APP_VER Application FW version
APP_MODE Application Mode
REFERENCE_LEVEL Reference Level
UNITS Amplitude units
SCALE Y axis scale
CENTER_FREQ Center freq
SIGNAL_STANDARD Current signal standard (the value is the index of the
signal standard list, where a value of 0 is the first
index in the list)
