3-3 :INSTrument Subsystem All Mode Commands
3-2 PN: 10580-00319 Rev. N S412E PM
3-3 :INSTrument Subsystem
One instrument may contain many logical instruments (“modes”). This subsystem controls
the selection of the current instrument mode.
:INSTrument:CATalog:FULL?
Title: Query Available Modes
Description: Returns a comma-separated list of available modes. Mode names are
enclosed in double quotes (“ ”). The application number immediately
follows the string name. For example: “HI_PM”10,”MWVNA”26
Cmd Parameter: NA (query only)
Query Response: NA (comma separated list)
Front Panel Access: Shift-9 (Mode) or Menu
:INSTrument:NSELect <integer>
:INSTrument:NSELect?
Title: Select Mode by Number
Description: Sets the instrument mode based on the value of <integer>. The
query version returns the number that is associated with the current
mode. Use :INSTrument:CATalog:FULL? to get a list of available
mode names and their integer representations.
Cmd Parameter: <NR1> (integer)
1 = SPA (Spectrum Analyzer mode)
10 = HI_PM (High Accuracy Power Meter mode)
18 = WIMAX_D (Fixed WiMAX mode)
19 = WIMAX_E (Mobile WiMAX mode)
26 = MWVNA (Microwave LMR Master mode)
29 = LTE (LTE Analyzer mode)
37 = P25 (P25 Analyzer mode)
44 = P25_2 (P25 Phase 2 Analyzer mode)
38 = NXDN (NXDN Analyzer mode)
50 = dPMR Signal Analyze
41 = DMR_2 (DMR 2 Analyzer mode)
Note
Switching modes can take longer than 80 seconds, depending on the application.
Add a delay of at least 90 seconds between mode switch commands. Anritsu
Company advises you to set the remote PC time-out to 120 seconds in order to
avoid unexpected time-out errors.
