5-11 [:SENSe] Subsystem VNA Commands
5-66 PN: 10580-00319 Rev. N S412E PM
[:SENSe]:AVERage Subsystem
This subsystem contains commands that are related to the combination of the data from
consecutive sweeps. Use commands in this subsystem to control sweep-to-sweep averaging
and max hold functionality.
[:SENSe]:AVERage:CLEar
Description: No query. Clears and restarts averaging of the measurement data. Note
that sweep averaging count must be set to greater than 1 for averaging
to restart.
Cmd Parameter: <char>
Query Response: NA (no query)
Front Panel Access: NA
[:SENSe]:AVERage:COUNt <integer>
[:SENSe]:AVERage:COUNt?
Description: Sets the number of traces to be averaged. Note that when averaging
count is set to be greater than 1, sweep averaging is turned on.
To stop averaging, set the averaging count to 1.
Cmd Parameter: <NR1> <integer>
Query Response: <NR1> <integer>
Default Value: 1
Range: 1 to 65535
Front Panel Access: Shift-3 (Sweep), Sweep Averaging
[:SENSe]:CALibration Subsystem
This subsystem controls the system calibration.
[:SENSe]:CALibration:STATe?
Description: Reports the calibrated state. This command returns a 0 if there is no
valid calibration, otherwise it returns the bit of the S parameters that
has a valid calibration. The bits are as follows:
For example, if a value of 5 is returned, then both of the S parameter
bits are valid (since decimal 5 is equivalent to binary 0101).
Cmd Parameter: NA (query only)
Query Response: <NR1> <integer> (0 to 5)
Front Panel Access: NA
S11 bit 0x01
S21 bit 0x04
