5-10 :Trace Subsystem VNA Commands
5-58 PN: 10580-00319 Rev. N S412E PM
TRACE_SMOOTHING_PERCENT Trace smoothing percent. This uses a bit mask
shift, where the bit shift mask is defined as:
PERC_SMOOTHING_BIT_SHIFT 8
PERC_SMOOTHING_BIT_MASK 0xFF
SMOOTHING_PERCENT Current active trace smoothing percent.
CURRENT_LIMIT The limit type (upper/lower) for the active trace.
Upper = 0 and Lower = 1
LIMIT_STATE The limit state (on/off) for the active trace.
On = 0, Off = 1
LIMIT_ALARM The limit alarm (on/off) for the active trace.
On = 0, Off = 1
LIMIT_MESSAGE Limit Pass Fail Message (on/off) for the active
trace. On = 0, Off = 1.
CURRENT_TEMPERATURE The current temperature. Valid only with a cal.
To get the temperature in Celsius divide the
result by 4.
TRACE_x_LP_MODE Currently not used.
TRACE_x_LP_RESPONSE_TYPE Currently not used.
TRACE_x_LP_PHASOR_IMPULSE Currently not used.
TRACE_x_POLAR_RESOLUTION Linear Polar Resolution, where x is the trace
number. Returned value is 1000 times the
resolution value
TRACE_x_POLAR_REFERENCE Linear Polar Reference value, where x is the
trace number. Returned value is 1000 times the
reference value
TRACE_x_POLAR_REFERENCE_LINE Currently not used
TRACE_x_LOG_POLAR_RESOLUTION Log Polar Resolution, where x is the trace
number. Returned value is in dB.
TRACE_x_LOG_POLAR_REFERENCE Log Polar Reference value, where x is the trace
number. Returned value is in dB.
TRACE_x_LOG_POLAR_REFERENCE_LI
NE
Currently not used
TRACE_x_REAL_Z_RESOLUTION Real Impedance resolution, where x is the trace
number. Returned value is 1000 times the
resolution value.
TRACE_x_REAL_Z_REFERENCE Real Impedance Reference value, where x is the
trace number. Returned value is 1000 times the
reference value.
TRACE_x_REAL_Z_REFERENCE_LINE Real Impedance Reference line, where x is the
trace number.
Table 5-3. Trace Header Parameters (Sheet 5 of 8)
Parameter Name Description
