6-2 :FETCh Subsystem Vector Voltmeter Commands
6-2 PN: 10580-00319 Rev. N S412E PM
:FETCh:VVM:DATA?
Description: Query only. Returns the most recent VVM measurement results. Data
is returned as 2 or 4 comma-separated values depending upon the
measurement type, measurement format, measurement mode, port, and
the reference setting. A “–” is returned for any data that is not valid at
that instance.
Cmd Parameter: NA (query only)
Query Response: NA (comma separated values)
Table 6-1. VVM Measurement Results
If Then Data Values
If the measurement type is Insertion,
and if the measurement mode is CW,
then data is returned as
4 comma-separated values
Amplitude
Phase
Reference Amplitude
Reference Phase.
If the measurement type is Insertion,
and if the measurement mode is CW
with save new reference set,
then data is returned as
4 comma-separated values
Relative Amplitude
Relative Phase
Reference Amplitude
Reference Phase.
If the measurement type is Return,
and if the measurement mode is CW,
and if format is set to dB,
then data is returned as
4 comma-delimited values
Amplitude
Phase
Reference Amplitude
Reference Phase.
If the measurement type is Return,
and if the measurement mode is CW
with save new reference set, and if
format is set to dB,
then data is returned as
4 comma-delimited values
Relative Amplitude
Relative Phase
Reference Amplitude
Reference Phase.
If the measurement type is Return,
and if format is set to VSWR,
then data is returned as
2 comma-delimited values
VSWR
Reference VSWR.
If the measurement type is Return,
and if the measurement mode is CW
with save new reference set, and if
format is set to VSWR,
then data is returned as
2 comma-delimited values
Relative VSWR
Reference VSWR.
If the measurement type is Return,
and if the measurement mode is CW,
and if format is set to Impedance,
then data is returned as
4 comma-delimited values
Real
Imaginary
Reference Real
Reference Imaginary.
If the measurement type is Return,
and if the measurement mode is CW
with save new reference set, and if
format is set to Impedance,
then data is returned as
4 comma-delimited values
Relative Real
Relative Imaginary
Reference Real
Reference Imaginary.
If the measurement mode is Table
with save new reference set,
then data is returned as
4 comma-separated values
Amplitude
Phase
Relative Amplitude
Relative Phase.
