12-11 :TRACe Subsystem NXDN Commands
12-30 PN: 10580-00319 Rev. N S412E PM
THD_MAPPING_EXCELLENT
Threshold at which the THD mapping value is deemed
excellent (Only used in NBFM).
THD_MAPPING_VERY_GOOD
Threshold at which the THD mapping value is deemed
very good (Only used in NBFM).
THD_MAPPING_GOOD
Threshold at which the THD mapping value is deemed
good (Only used in NBFM).
THD_MAPPING_FAIR
Threshold at which the THD mapping value is deemed
fair (Only used in NBFM).
THD_MAPPING_POOR
Threshold at which the THD mapping value is deemed
poor (Only used in NBFM).
AUTO_SCAN
State of auto scan. Determines if instrument will
automatically scan for a signal and set the receiver
frequency to the signal with the highest signal strength
(Only used in NBFM). 1 is OFF and 0 is ON.
OCC_BW_METHOD
Occupied bandwidth method (Only used in NBFM).
0 is % Int Power and 1 is > dBc.
OCC_BW_PERCENT % Int Power (Only used in NBFM).
OCC_BW_DBC > dBc (Only used in NBFM).
TONE_TYPE
Tone type selection (Only used in NBFM). Determines
display of the last summary slot. 0 is CTCSS, 1 is
DCS, and 2 is DTMF.
CTCSS_FREQ
Frequency of CTCSS generator pattern (Only used in
NBFM).
DCS_TYPE Type of DCS generator pattern (Only used in NBFM).
DTMF_TONE Tone of DTMF generator pattern (Only used in NBFM).
FREQ_DISPLAY_TYPE
Determines whether carrier frequency or frequency
error is shown in the summary window (Only used in
NBFM). 0 is Carrier Frequency, 1 is Frequency Error.
TONE_DEVIATION
Tone deviation for the nbmf_ctcss, nbfm_dcs,
nbfm_1khz_ctcss, and nbfm_1khz_dcs generator
patterns (Only used in NBFM).
IF_BANDWIDTH
IF Bandwidth setting (Only used in NBFM). 0 is 5 kHz,
1 is 6.25 kHz, 2 is 10 kHz, 3 is 12.5 kHz, 4 is 30 kHz,
5 is 50 kHz.
IF_BANDWIDTH_PERCENT
Percent of IF Bandwidth used to calculate Y-Axis for
Audio Spectrum and Audio Waveform graphs in NBFM
Analyzer (Only used in NBFM).
WACN_ID Not used.
SYSTEM_ID Not used.
COLOR_CODE Not used.
Table 12-1. Returned Parameter Values in Trace Preamble (Sheet 7 of 7)
Parameter Name Description
