4-11 :TRACe Subsystem Spectrum Analyzer Commands
4-40 PN: 10580-00319 Rev. N S412E PM
IMPEDANCE Input impedance
REFERENCE_FREQUENCY Reference freq
SET_SWEEP_TIME Minimum sweep time setting
TRIGGER_TYPE Trigger type
VIDEO_TRIGGER_LEVEL Video trigger level
TRIGGER_POSITION Trigger position as a percent of the display
PEAK_THRESHOLD Marker peak search threshold
MARKER_TABLE Marker table status
ACTIVE_ MEASUREMENT Current measurement
ANTENNA Antenna index
OCC_BW_METHOD Occupied bandwidth method
OCC_BW_PERCENT Occupied bandwidth % of power setting
OCC_BW_DBC Occupied bandwidth dBc setting
OCC_BW_MEASURED_ DB Occupied bandwidth measured dBc value
OCC_BW_MEASURED_ PERCENT Occupied bandwidth measured % value
OCC_BW_VALUE Measured occupied bandwidth
OCC_BW_LINE_ MARKER_INFO Mask off 16 bits at a time to get the display point
location of the 3 OBW display indicators
CH_PWR_WIDTH Channel power integration bandwidth
CH_PWR_VALUE Measured channel power
CH_PWR_DENSITY Measured channel power density
CH_PWR_LINE_ MARKER_INFO Mask off 16 bits at a time to get the display point
location of the 2 channel power display indicators
ACPR_MAIN_CH_BW ACPR main channel bandwidth
ACPR_ADJC_CH_BW ACPR adjacent channel bandwidth
ACPR_CHANNEL_ SPACING ACPR channel spacing
ACPR_MAIN_CH_PWR ACPR measured main channel power
ACPR_UPPER_CH_PWR ACPR measured upper channel power
ACPR_LOWER_CH_ PWR ACPR measured lower channel power
ACPR_LOWER_CH_
LINE_MARKER_INFO
Mask off 16 bits at a time to get the display point
location of the 2 ACPR lower channel display
indicators
ACPR_MAIN_CH_LINE_
MARKER_INFO
Mask off 16 bits at a time to get the display point
location of the 2 ACPR main channel display
indicators
Table 4-1. Available Parameters in Spectrum Analyzer Mode (Sheet 3 of 5)
Parameter Name Description
