4-11 :TRACe Subsystem Spectrum Analyzer Commands
4-42 PN: 10580-00319 Rev. N S412E PM
MKR_SPA_FLAGSx Reference marker x flags:
SPA_MKR_FLAG_ON_OFF: 0x00000001
SPA_MKR_FLAG_DELTA_MKR: 0x00000002
SPA_MKR_FLAG_SELECTED: 0x00000004
SPA_MKR_FLAG_DATA_INVALID: 0x00000008
SPA_MKR_FLAG_DATA_STALE: 0x00000010
SPA_MKR_FLAG_FIXED: 0x00000020
SPA_MKR_FLAG_MASK: 0x000000FF
SPA_MKR_FLAG_DISPL_AMPL_HZ: 0x00000100
SPA_MKR_FLAG_DISPL_AMPL_PER_HZ:
0x00000200
SPA_MKR_FLAG_DISP_FLAG: 0x00000F00
SPA_MKR_FLAG_RELATIVE: 0x00001000
SPA_MKR_STANDARD: 0x10000000
SPA_MKR_FIELD_STRENGHT: 0x20000000
SPA_MKR_NOISE: 0x30000000
SPA_MKR_COUNTER: 0x40000000
SPA_MKR_TIME: 0x50000000
MKR_SPA_REF_TOx Specifies which marker is the marker x reference to
MKR_SPA_TRACex Specifies which trace the marker x is for.
LIM_LFLAGS_UP Upper limit flags:
LIMIT_FLAG_ON: 0x00000004
LIMIT_FLAG_ALARM_ON: 0x00000002
LIM_FREQNC_UPx Upper limit point x freq (where x is the limit point
number starting with 0)
LIM_MAGNTD_UPx Upper limit point x amplitude
LIM_LFLAGS_LO Lower limit flags:
LIMIT_FLAG_ON: 0x00000004
LIMIT_FLAG_ALARM_ON: 0x00000002
LIM_FREQNC_LOx Lower limit point x freq (where x is the limit point
number starting with 0)
LIM_MAGNTD_LOx Lower limit point x amplitude
Table 4-1. Available Parameters in Spectrum Analyzer Mode (Sheet 5 of 5)
Parameter Name Description
