5-23
Note :
When sending a program message and OM is 0 or 1, the OM mode will automatically switch to 2.
<Numeric output format>
FSG– 12345678901 . 2E+0CRLF
D1
D2 D3 D4 D5 D6 D7
D1 : Indicates the data type.
F: Frequency (Hz)
R: Parts per million (ppm)
W: Pulse width (s)
P: Pulse continuous period (s)
D2 : Indicates whether or not to perform an offset calculation.
S: Offset On
Blank space : Offset Off
D3 : Indicates whether or not to perform invalid display for read values, judgment results for specifications, or
statistics processing.
U: UNCAL
L: No-Go (Lower side)
H: No-Go (Higher side)
G: Go
M: Mean value
X: Maximum value
N: Minimum value
P: P–P
: The above is Off Low
High (priority)
(Blank)
(When there is more than one condition, the one with the highest priority is attached.)
D4 : A data code is attached.
–: Data code is a minus sign –
Blank space : Data code is a plus sign +
D5 : Numeric data represented by twelve digits and one floating point digit.
5.4 Device Message List
