Table 1-6 Standard Specifications (Continued)
MF2414B
10.2
(1)
(2)
(3)
10.3
(1)
(2)
(3)
11
11.1
11.2
Modulated-pulse width
measurement
Resolution
Accuracy
Units displayed
Pulse-modulated measurement
Resolution
Accuracy
Units displayed
Frequency
(CW measurement)
Resolution/counting time
Measurement accuracy Input1
Input2
Item
1 ns
± 20 ns ± time base accuracy × measurement pulse width ± trigger error
µs fixed display
1 ns
± 20 ns ± time base accuracy × measurement pulse width ± trigger error
µs fixed display
Input1 : 1 MHz/1 us to 0.1 Hz/10 s (Normal)
1 MHz/0.18 us to 0.1 Hz/1.8 s (Fast, Typical value)
Input2 : 10 MHz to 1 GHz (50 Ω) will be 1 MHz/1 us to 0.1 Hz/10s
10 Hz to 10 MHz (1 M Ω) will be according to the following chart
Count mode Normal :
±1 count ± time base accuracy × measurement frequency
± Residual error 1 (measurement frequency (GHz)/10 count (rms))
Fast : ±1 count ± time base accuracy
× measurement frequency ± trigger
error
± Residual error 2 (measurement frequency (GHz)/2 count (rms))
10 MHz to 1 GHz : ±1 count ± time base accuracy
× measurement frequency
10 Hz to 10 MHz : ±1 count ± time base
accuracy × measurement frequency
±trigger error
MF2412B MF2413B
10 s
10
1
2
1 s
100 m
10 m
1 m
100µ
10 100 1 k 10 k 100 k 1 M 10 M
10
2
10
3
10
4
10
5
10
6
10
7
10
8
100 M 1 G
Measurement Time (s)
Input Frequency (Hz)
Measurement Period (Count)
(1mHz) (10mHz)
(100 mHz)
(1 Hz)
(10 Hz)
(100 Hz)
