Table 1-6 Standard Specifications (Continued)
MF2414B
14
14.1
14.2
14.3
14.4
14.5
15
15.1
15.2
High-speed sample
Frequency resolution
Frequency accuracy
Time accuracy
Data count
Sample rate
Template function
Limit frequency range
Setting resolution
Item
Input 1: High-speed sample rate vs. frequency resolution
Input 2: High-speed sample rate vs. frequency resolution
(Measurement frequency: 100 MHz)
±1 count ±reference signal × measurement frequency ±trigger error
±Residual error 2 (measured frequency (GHz)/2 count (rms))
Input 1: ±reference signal accuracy × measurement time ±trigger error ±800 ns
Input 2: ±reference signal accuracy
× measurement time ±trigger error
±64/measurement frequency
100 to 2000 (1-2-5 step)
10 us to 1 ms (1-2-5 step)
MF2412A: 0 Hz to 20 GHz
MF2413A: 0 Hz to 27 GHz
MF2414A: 0 Hz to 40 GHz
1 Hz
MF2412B MF2413B
High-speed Sample Rate
10 us
100 us
1 ms
Frequency resolution
10 kHz
1 kHz
100 Hz
High-speed Sample Rate
10 us
100 us
1 ms
Frequency resolution
100 kHz
10 kHz
1 kHz
