13.5 Network Configuration Object (04h)
Category
Extended
Object Description
This object holds network specific configuration parameters that may be set by the end user. A reset com-
mand (factory default) issued towards this object will result in all instances being set to their default values.
As soon as the used combination of IP address, Subnet mask and Gateway is changed, the module informs
the application by writing the new set to instance #1, attribute #16 in the Ethernet Host Object (F9h).
See also...
• Communication Settings, p. 12
• E-mail Client, p. 44
• Ethernet Host Object (F9h), p. 203
Allowing the following instances to be set by the host application during start-up will inhibit the
possibility to pass conformance tests.
Supported Commands
Object: Get_Attribute
Reset
Instance: Get_Attribute
Set_Attribute
Get_Enum_String
Object Attributes (Instance #0)
# Name Access Data Type Value Description
3 Number of instances Get UINT16 13 Supported number of instances
4 Highest instance
number
Get UINT16 21 Highest instance number
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
