3.4 Network Data Exchange
3.4.1 Application Data Instances (ADIs)
ADIs can be accessed acyclically from the network by means of Record Data read/write serv-
ices. If addressed through a given API and Index range, the module translates the service into
standard object requests towards the Application Data Object. If the host application responds
with an error to such a request, that error will be translated to PROFINET standard.
The following parameters affect the addressing of ADIs onPROFINET:
Application Process
Instance (API)
API 0 (zero) provides access to data in the Application Data Object, i.e. the ADIs.
Acyclic requests towards other APIs will be forwarded to the PROFINET IO
Object (F6h), p. 184 by means of the ‘Get_Record’ and ‘Set_Record’-commands.
The remainder of this section assumes API 0 (zero).
Slot & subslot The Slot and subslot values have no impact on the actual addressing of ADIs,
except that the actual Slot and subslot needs to be populated with a module/
submodule. This is always true for the DAP (Device Access Point), which
occupies Slot #0/subslot #1. Other Slot/subslot values can also be used provided
that the implementation populates it with a module/submodule.
Index There is a 1:1 correlation between ADI and index as long as the index number is
less than - or equal to - 7FFFh. Index 0 (zero) is not associated with an ADI and
cannot be used.
API Slot Subslot Index ADI Comments
0 0 1 0000h
-
(not associated with ADIs)
0001h 1 Device Access Point (DAP)
0002h 2
... ...
7FFFh 32767
8000h...FFFFh
-
(not associated with ADIs)
X (>0) Y 0000h
0001h 1 Conditional; X and Y must be
populated
0002h 2
... ...
7FFFh 32767
8000h...FFFFh
-
(not associated with ADIs)
>0
- - - -
See Application Process Instances
(API), p. 18
See also...
• Caveats, p. 14
• Application Process Instances (API), p. 18
• PROFINET IO Object (F6h), p. 184
