Anybus CompactCom 40 User Manual

Anybus Module Objects 91 (258)
13.3 Diagnostic Object (02h)
Category
Extended
Object Description
This object provides a standardized way of handling host application events & diagnostics, and is thoroughly
described in the general Anybus CompactCom 40 Software Design Guide.
Supported Commands
Object: Get_Attribute
Create
Delete
Instance: Get_Attribute
Object Attributes (Instance #0)
# Name Access Data Type Value
1... 4
- - -
Consult the general Anybus CompactCom 40 Software Design
Guide for further information.
11 Max no. of instances Get UINT16 5+1 (Of the maximum number of instances there should always
be one instance reserved for an event of severity level ‘Major,
unrecoverable’, to force the module into the ‘EXCEPTION’-
state.)
12 Supported
functionality
Get BITS32 Bit 0: “0” (Latching events are not supported)
Bit 1 - 31: reserved (shall be “0” )
Instance Attributes (Instance #1)
Extended
# Name Access Data Type Value
1 Severity Get UINT8 Consult the general Anybus CompactCom 40 Software Design
Guide for further information.
2 Event Code Get UINT8
3 NW specific data Get Array of
UINT8
Optional network specific information, see below.
4 Slot Get UINT16 Consult the general Anybus CompactCom 40 Software Design
Guide for further information.
5 ADI Get UINT16
6 Element Get UINT8
7 Bit Get UINT8
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
