Anybus CompactCom 40 User Manual

Appendix H: Backward Compatibility 230 (258)
H.2 Hardware Compatibility
Anybus CompactCom is available in three hardware formats; Module, Chip, and Brick.
H.2.1 Module
The modules in the 30-series and the 40-series share physical characteristics, like dimensions,
outline, connectors, LED indicators, mounting parts etc. They are also available as modules
without housing.
Fig. 24 Anybus CompactCom M30/M40
H.2.2 Chip
The chip (C30/C40) versions of the Anybus CompactCom differ completely when it comes to
physical dimensions.
There is no way to migrate a chip solution from the 30-series to the 40-series
without a major hardware update.
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
