Anybus CompactCom 40 User Manual

Anybus Module Objects 90 (258)
13.2 Anybus Object (01h)
Category
Basic
Object Description
This object assembles all common Anybus data, and is described thoroughly in the general Anybus
CompactCom 40 Software Design Guide.
Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
Set_Attribute
Get_Enum_String
Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
Basic
# Name Access Type Value
1 Module type Get UINT16 0403h (Standard Anybus Compact-
Com 40)
2... 11
- - -
Consult the general Anybus Com-
pactCom 40 Software Design Guide
for further information.
12 LED colors Get struct of: Value: Color:
UINT8 (LED1A) 01h Green
UINT8 (LED1B) 02h Red
UINT8 (LED2A) 01h Green
UINT8 (LED2B) 02h Red
13... 16
- - -
Consult the general Anybus Com-
pactCom 40 Software Design Guide
for further information.
17 Virtual attributes Get/Set
18 Black list/White list Get/Set
19 Network time Get UINT64 0 (Not supported)
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
