Anybus CompactCom 40 User Manual

Anybus Module Objects 135 (258)
Object Attributes (Instance #0)
# Name Access Data Type Value
1 Name Get Array of
Char
“Network PROFINET IO”
2 Revision Get UINT8 01h
3 Number of instances Get UINT16 0001h
4 Highest instance
number
Get UINT16 0001h
Instance Attributes (Instance #1)
Extended
# Name Access Type Value
1 OnLineTrans Get UINT32 Diagnostic counters; keeps track of the number of on-line
transitions
2 OffLineTrans Get UINT32 Diagnostic counters; keeps track of the number of off-line
transitions
3 (reserved)
4 Last AbortInd
ReasonCode
Get UINT16 Reason code for most recent Abort indication
See command details for command AR_Abort
5 AddedApis Get UINT16 Returns the number of APIs added (including API 0)
6 ApiList Get Array of
UINT32
First element will always be zero and the second element will
contain an additional API. Length of the array is determined by
parameter "AddedApis".
7 EstablishedArs Get UINT16 The number of Application Relationships currently established
8 ArList Get Array of
UINT16
Array of Application Relationship handles. Length of array is de-
termined by parameter "EstablishedArs".
9
- - - -
10 Port 1 MAC Address Get Array of
UINT8
6 Byte PROFINET Port 1 MAC address
See also...
- Ethernet Host Object (F9h), p. 203
11 Port 2 MAC Address Get Array of
UINT8
6 Byte PROFINET Port 2 MAC address
See also...
- Ethernet Host Object (F9h), p. 203
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
