Host Application Objects 184 (258)

14.7 PROFINET IO Object (F6h)

Category

Basic, extended

Object Description

This object implements PROFINET IO related settings in the host application.

The implementation of this object is optional; the host application can support none, some, or all of the attrib-

utes specified below. The module will attempt to retrieve the values of these attributes during startup; if an at-

tribute is not implemented in the host application, simply respond with an error message (06h, “Invalid

CmdExt[0]”). In such a case, the module will use its default value.

If the module attempts to retrieve a value of an attribute not listed below, respond with an error message

(06h, “Invalid CmdExt[0]”).

See also...

• Network PROFINET IO Object (0Eh), p. 133

• Flowchart — Record Data Access, p. 210

• Anybus CompactCom 40 Software Design Guide, “Error Codes”

Supported Commands

Object: Get_Attribute (01h)

Get_Record (10h, see below)

Set_Record (11h, see below)

AR_Check_Ind (14h, see below)

Cfg_Mismatch_Ind (15h, see below)

Expected_Ident_Ind (1Bh, see below)

End_Of_Prm_Ind (17h, see below)

AR_Abort_Ind (19h, see below)

Indicate_Device (1Eh, see below)

Instance: Get_Attribute (01h)

Object Attributes (Instance #0)

# Name Access Data Type Value

1 Name Get Array of

CHAR

“PROFINET IO”

2 Revision Get UINT8 01h

3 Number of instances Get UINT16 0001h

4 Highest instance no. Get UINT16 0001h

Anybus

®

CompactCom

™

40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
