Anybus CompactCom 40 User Manual

Modular Device 32 (258)
5 Modular Device
5.1 General
The modular device concept is useful when creating a configuration based on reusable mod-
ules, for example when modelling a backplane device with pluggable modules.
The first slot (slot 0) is always occupied by the Device Access Point (DAP) module, which repre-
sents the head node where the Anybus CompactCom is located. It is not allowed to add a proc-
ess data mapping for any ADI within the range of slot 0. The remaining slots are assigned fixed
ranges of ADIs, set up using the Modular Device Object. A GSD module can represent different
ADIs, depending on which slot it occupies, making it possible to create a configuration based
on reusable modules. This is not possible in ADI based RI mode.
See also ...
• “ Modular Device Object (ECh)” (see Anybus CompactCom 40 Software Design Guide)
5.2 Modular Device RI
The RI, when implementing a modular device, is generated from the Module IDs as defined in
the Modular Device Object (ECh) (see the Anybus CompactCom 40 Software Design Guide)
and from the process data mappings as shown in the example below.
Module ID: 0x0000004
Submodule ID: 0x00010203
0x0 0: Mapped to Write PD area
1: Mapped to Read PD area
001 ADI index
02 Number of elements to map
03 ADI start element #
A set of conditions must be fulfilled for the Anybus CompactCom to use the Modular Device RI:
• The Modular Device object implemented must be of revision 1.
• Modular device object attributes #11 and #12 must be readable and valid
– Number of slots must be: 0 < NumSlots <= 256
– ADIs per slot must be: 0 < AdisPerSlot <= 4096
• The list with Module Type IDs must contain “NumSlots” items.
5.3 Remap
For a host application not supporting remap, the modules must contain a fixed set of submod-
ules (GSD attribute FixedInSubslots), where the process data mapping of each slot is per-
formed in accordance with the GSD definition of each particular module type. See Modular
Device Example, p. 33, where slot 1 and slot 3 have the same module ID and also matching
process data mapping commands.
If remap is supported by the application the GSD modules may be designed in a flexible manner
with pluggable submodules (GSD attributes AllowedInSubslots / UsedInSubslots). If the config-
uration results in an expected identification that differs from the real identification the Anybus
CompactCom will attempt to resolve the mismatch according to Configuration Mismatch, p. 21.
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
