PROFINET Implementation Details 21 (258)
4.4.2 Configuration Mismatch
General
A configuration mismatch occurs when the Real Identification (RI) does not match the Expected
Identification. Depending on how the RI configuration is established, the Anybus CompactCom
40 PROFINET IRT will first try to resolve the mismatch as described in the applicable section
below (Resolving Mismatch for default configuration or custom configuration). If this attempt to
resolve the mismatch fails, the Anybus CompactCom 40 PROFINET IRT will provide indications
as described in Further Actions to Resolve Mismatch, p. 22.
Resolving Mismatch (Default Configuration)
If the Real Identification has been established according to the default mode, the Anybus Com-
pactCom 40 PROFINET IRT will try to remap the Real Identification to match the Expected
Identification.
The application must have implemented support for the remap commands in the
Application Data object (FEh), for remap to be possible.
As the Module ID contains the ADI number and the Submodule ID describes I/O direction and
element section, all information required to perform a remap is available.
The application must be able to respond with the data type for every ADI, or a remap is not
possible.
The remap is performed as follows:
• A request is sent to remap the read area. If this request is rejected no change is made to
the process data map and the Real Identification.
• If the read area remap succeeds, a write remap request is sent. If this is rejected, the proc-
ess data map is in an inconsistent state and new remap commands are sent that will re-
move all mappings.
• If both the read and the write remap requests succeed a new Real Identification will be built
to match the Expected Identification.
See also ...
• Default Configuration Mismatch, p. 213 (flowchart)
• Application Data Object (FEh) (see Anybus CompactCom 40 Software Design Guide)
Resolving Mismatch (Custom Configuration)
If a configuration mismatch occurs for a custom configuration, the Anybus CompactCom 40
PROFINET IRT will issue the command Expected_Ident_Ind to the host application. If the host
application intends to change the Real Identification based on the Expected Identification, it re-
sponds with “Block” and performs the required Pull/Plug operations, before sending an Ident_
Change_Done command to the Network PROFINET IO Object (0Eh).
See also ....
• Custom Configuration mismatch, p. 214 (flowchart)
• Expected_Ident_Ind, see command details in PROFINET IO Object (F6h), p. 184
• Ident_Change_Done, see command details in Network PROFINET IO Object (0Eh), p. 133
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
