Anybus CompactCom 40 User Manual

D Secure HICP (Secure Host IP Configuration
Protocol)
D.1 General
The Anybus CompactCom 40 PROFINET IRT supports the Secure HICP protocol used by the
Anybus IPconfig utility for changing settings, e.g. IP address, Subnet mask, and enable/disable
DHCP. Anybus IPconfig can be downloaded free of charge from the HMS website, www.anybus.
com. This utility may be used to access the network settings of any Anybus product connected
to the network via UDP port 3250.
The protocol offers secure authentication and the ability to restart/reboot the device(s).
D.2 Operation
When the application is started, the network is automatically scanned for Anybus products. The
network can be rescanned at any time by clicking Scan.
To alter the network settings of a module, double-click on its entry in the list. A window will ap-
pear, containing the settings for the module.
Fig. 21
Validate the new settings by clicking Set, or click Cancel to cancel all changes. Optionally, the
configuration can be protected from unauthorized access by a password. To enter a password,
check the Change password checkbox and enter the password in the New password text
field.
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
