Anybus CompactCom 40 User Manual

Host Application Objects 203 (258)
14.8 Ethernet Host Object (F9h)
Object Description
This object implements Ethernet features in the host application.
Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
Set_Attribute
Object Attributes (Instance #0)
# Name Access Data Type Value
1 Name Get Array of CHAR “Ethernet”
2 Revision Get UINT8 02h
3 Number of instances Get UINT16 0001h
4 Highest instance no. Get UINT16 0001h
Instance Attributes (Instance #1)
• If an attribute is not implemented, the default value will be used.
• The module is preprogrammed with a valid MAC address. To use that address, do not implement attrib-
ute #1.
• Do not implement attributes #9 and #10, only used for PROFINET devices, if the module shall use the
preprogrammed MAC addresses.
• If new MAC addresses are assigned to a PROFINET device, these addresses (in attributes #1, #9, and
#10) have to be consecutive, e.g. (xx:yy:zz:aa:bb:01), (xx:yy:zz:aa:bb:02), and (xx:yy:zz:aa:bb:03) with
the first five octets not changing.
# Name Ac-
cess
Data Type Default
Value
Comment
1 MAC address Get Array of
UINT8
-
6 byte physical address value; overrides the preprog-
rammed Mac address. Note that the new Mac address
value must be obtained from the IEEE.
Do not implement this attribute if the preprogrammed Mac
address is to be used.
2 Enable HICP Get BOOL True
(Enabled)
Enable/Disable HICP
3 Enable Web
Server
Get BOOL True
(Enabled)
Enable/Disable Web Server
(Not used if Transparent Ethernet is enabled.)
4 (reserved) Reserved for Anybus CompactCom 30 applications.
5 Enable Web ADI
access
Get BOOL True
(Enabled)
Enable/Disable Web ADI access
(Not used if Transparent Ethernet is enabled.)
6 Enable FTP
server
Get BOOL True
(Enabled)
Enable/Disable FTP server
(Not used if Transparent Ethernet is enabled.)
7 Enable admin
mode
Get BOOL False
(Disabled)
Enable/Disable FTP admin mode
(Not used if Transparent Ethernet is enabled.)
8 Network Status Set UINT16
-
See below.
