Anybus CompactCom 40 User Manual

Host Application Objects 204 (258)
# Name Ac-
cess
Data Type Default
Value
Comment
9 Port 1 MAC
address
Get Array of
UINT8
-
Note: This attribute is only valid for PROFINET devices.
6 byte MAC address for port 1 (mandatory for the LLDP
protocol).
This setting overrides any Port MAC address in the host
PROFINET IO Object.
Do not implement this attribute if the preprogrammed Mac
address is to be used.
10 Port 2 MAC
address
Get Array of
UINT8
-
Note: This attribute is only valid for PROFINET devices.
6 byte MAC address for port 2 (mandatory for the LLDP
protocol).
This setting overrides any Port MAC address in the host
PROFINET IO Object.
Do not implement this attribute if the preprogrammed Mac
address is to be used.
11 Enable ACD Get BOOL True
(Enabled)
Enable/Disable ACD protocol.
If ACD functionality is disabled using this attribute, the
ACD attributes in the CIP TCP/IP object (F5h) are not
available.
12 Port 1 State Get ENUM 0 (Enabled) The state of Ethernet port 1.
• This attribute is not read by EtherCAT and Ethernet
POWERLINK devices, where Port 1 is always
enabled.
• This attribute is not used by PROFINET and Ethernet
POWERLINK
00h: Enabled
01h: Disabled.
The port is treated as existing. References to
the port can exist, e.g. in network protocol or
on website.
13 Port 2 State Get ENUM 0 (Enabled) The state of Ethernet port 2.
• This attribute is not read by EtherCAT and Ethernet
POWERLINK devices, where Port 2 is always
enabled.
• This attribute is not used by PROFINET
00h: Enabled
01h: Disabled.
The port is treated as existing. References to
the port can exist, e.g. in network protocol or
on website.
02h: Inactive.
The attribute is set to this value for a device
that only has one physical port. All two-port
functionality is disabled. No references can
be made to this port.
Note: This functionality is available for Ether-
net/IP and Modbus-TCP devices.
14 (reserved)
15 Enable reset
from HICP
Get BOOL 0 = False Enables the option to reset the module from HICP.
16 IP configuration Set Struct of:
UINT32 (IP
address)
UINT32
(Subnet
mask)
UINT32
(Gateway)
N/A Whenever the configuration is assigned or changed, the
Anybus CompactCom module will update this attribute.
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
