Anybus CompactCom 40 User Manual

Anybus Module Objects 92 (258)
Major unrecoverable events cause the module to disconnect itself from the network, thus preventing network
participation. Other severity levels either produce a Channel Diagnostic entry/alarm or a Generic Diagnostic
entry/alarm, depending on the Event Code:
Event Code Result
0...FEh Module issues a Channel Diagnostic entry/alarm. The Event Code will be translated and represented as the
Channel Error Type as follows:
Code: Event (Anybus): Channel Error Type (PROFINET):
10h Generic Error Error
20h Current Short circuit
21h Current, device input side Short circuit
22h Current, inside the device Short circuit
23h Current, device output side Short circuit
30h Voltage Overvoltage
31h Mains Voltage Overvoltage
32h Voltage inside the device Overvoltage
33h Output Voltage Overvoltage
40h Temperature Overtemperature
41h Ambient Temperature Overtemperature
42h Device Temperature Overtemperature
50h Device Hardware Error
60h Device Software Error
61h Internal Software Error
62h User Software Error
63h Data Set Error
70h Additional Modules Error
80h Monitoring Error
81h Communication Error
82h Protocol Error Error
90h External Error Error
F0h Additional Functions Error
FFh Module issues a Generic Diagnostic entry/alarm based on network specific data.
See details below.
Details: Network Specific Data
Network specific diagnostic data serves as the payload in the PROFINET diagnostic alarm. The data contains
an identifier (UserStructureIdentifier) that describes the structure of the data.
The following identifier values are supported:
• 8000h (Channel Diagnostic)
• 8002h (Extended Channel Diagnostic)
• 8003h (Qualified Channel Diagnostic)
Byte Contents
1 UserStructureIdentifier, low byte
2 UserStructureIdentifier, high byte
3... 16 Data
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
