Anybus CompactCom 40 User Manual

Anybus Module Objects 132 (258)
# Name Access Data Type Description
5
Interface Counters Get Array of
UINT32
Array containing MIB-II interface counters (rfc1213)
See table below for array indices.
6 Media Counters Get Array of
UINT32
Array containing Ethernet-Like MIB counters for the port.
See table below for array indices.
Note: This attribute is not valid for the internal port, i.e. instance
#1 of the object
Interface Counters
: Array indices of Interface Counters attribute (#5)
Index Name Description
0 In octets Octets received on the interface
1 In Unicast Packets Unicast packets received on the interface
2 In Non-Unicast Packets Non-unicast packets (multicast/broadcast) packets received on the interface
3 In Discards Inbound packets received on the interface but discarded
4 In Errors Inbound packets that contain errors (does not include In Discards)
5 In Unknown Protos Inbound packets with unknown protocol
6 Out Octets Octets transmitted on the interface
7
Out Unicast packets Unicast packets transmitted on the interface
8 Out Non-Unicast Packets Non-unicast (multicast/broadcast) packets transmitted on the interface
9 Out Discards Outbound packets discarded
10 Out Errors Outbound packets that contain errors
Media Counters
: Array indices of Media Counters attribute (#6)
Index Name Description
0 AlignmentErrors; Frames received that are not an integral number of octets in length
1 FCSErrors; Frames received that do not pass the FCS check
2 SingleCollisions; Successfully transmitted frames which experienced exactly one collision
3 MultipleCollisions; Successfully transmitted frames which experienced more than one collision
4 SQETestErrors; Number of times SQE test error is generated
5
DeferredTransmissions; Frames for which first transmission attempt is delayed because the medium is
busy
6 LateCollisions; Number of times collision is detected later than 512 bit-times into the transmis-
sion of a packet
7
ExcessiveCollisions; Frames for which transmission fails due to excessive collisions
8 lMACTransmitErrors; Frames for which transmission fails due to an internal MAC sublayer transmit
error
9 lCarrieSenseErrors; Times that the carrier sense condition was lost or never asserted when at-
tempting to transmit a frame
10 lFrameTooLong; Frames received that exceed the maximum permitted frame size
11 lMACRecieveErrors; Frames for which reception on an interface fails due to an internal MAC sub-
layer receive error
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
