Command Details: Cfg_Mismatch_Ind
Category
Extended
Details
Command Code 15h
Valid for: Object Instance
Description
The module issues this command to inform the host application that the configuration in the IO Controller (i.e.
the Expected Identification) does not match the configuration defined by the host application (i.e. the Real
Identification).
It is optional to implement support for this command.
• Command Details
Field Contents Comments
CmdExt[0] AR handle (low byte) Handle for the Application Relationship (AR)
CmdExt[1] AR handle (high byte)
MsgData[0] API (low word, low byte) Application Process Instance (API)
MsgData[1] API (low word, high byte)
MsgData[2] API (high word, low byte)
MsgData[3] API (high word, high byte)
MsgData[4] Slot (low byte) Slot number of mismatch
MsgData[5] Slot (high byte)
MsgData[6] Subslot (low byte) Subslot number of mismatch
MsgData[7] Subslot (high byte)
MsgData[8] Expected Module Identifier (low word, low
byte)
Module identifier (as stated in the GSD file) derived from
the IO Controller configuration
MsgData[9] Expected Module Identifier (low word, high
byte)
MsgData[10] Expected Module Identifier (high word, low
byte)
MsgData[11] Expected Module Identifier (high word, high
byte)
MsgData[12] Expected Submodule Identifier (low word,
low byte)
Submodule identifier (as stated in the GSD file) derived
from the IO Controller configuration
MsgData[13] Expected Submodule Identifier (low word,
high byte)
MsgData[14] Expected Submodule Identifier (high word,
low byte)
MsgData[15] Expected Submodule Identifier (high word,
high byte)
• Response Details
(no data)
