Anybus CompactCom 40 User Manual

Server Side Include (SSI) 61 (258)
• Command Data Types (c_type)
For types which support arrays, the number of elements can be specified using the suffix
[n], where n specifies the number of elements. Each data element must be separated by
space.
Type Supports Arrays Data format (as supplied in msgdata)
BOOL Yes 1
SINT8 Yes -25
SINT16 Yes 2345
SINT32 Yes -2569
UINT8 Yes 245
UINT16 Yes 40000
UINT32 Yes 32
CHAR Yes A
STRING No “abcde”
Note: Quotes can be included in the string if preceded by back-
slash(“\”)
Example: “We usually refer to it as \‘the Egg\’”
FLOAT Yes 5.6538e2
NONE No Command holds no data, hence no data type
• Response Data Types (r_type)
For types which support arrays, the number of elements can be specified using the suffix
[n], where n specifies the number of elements.
Type Supports Arrays Data format (as supplied in msgdata)
BOOL Yes Optionally, it is possible to exchange the BOOL data with a mes-
sage based on the value (true or false). In such case, the actual
data type returned from the function will be STRING.
Syntax: BOOL<true><false>
For arrays, the format will be BOOL[n]<true><false>.
SINT8 Yes
-
SINT16 Yes
-
SINT32 Yes
-
UINT8 Yes This type can also be used when reading ENUM data types from
an object. In such case, the actual ENUM value will be returned.
UINT16 Yes
-
UINT32 Yes
-
CHAR Yes
-
STRING No
-
ENUM No When using this data type, the ABCCMessage() function will first
read the ENUM value. It will then issue a ‘Get Enum String’-com-
mand to retrieve the actual enumeration string. The actual data
type in the response will be STRING.
FLOAT Yes
-
NONE No Response holds no data, hence no data type
It is important to note that the message will be passed transparently to the
addressed object. The SSI engine performs no checks for violations of the object
addressing scheme, e.g. a malformed Get_Attribute request which (wrongfully)
includes message data will be passed unmodified to the object, even though this is
obviously wrong. Failure to observe this may cause loss of data or other undesired
side effects.
