Anybus CompactCom 40 User Manual

SNMP Agent 86 (258)
11.4.2 Interfaces Group Variables
Access authorizations for all variables are read only with values from internal sources. The
number in brackets refers to the port number (1 - Port 1, 2 - Port 2, 3 - Internal port)
If nothing else is specified, the value of a variable is 0
Variable Data Type Value Description
ifNumber integer 3 Number of network interfaces present.
Constant
IfIndex(1..3) integer ifIndex(1) = 1
ifIndex(2) = 2
ifIndex(3) = 3
Unique value for each interface. Constant
ifDescr(1..3) octetstring ifDescr(1) = “port-
001”
ifDescr(2) = “port-
002”
ifDescr(3) = “port-
internal”
Information about the interface. ifDescr(1)
must equal "port-001"and ifDescr(2) = "port-
002" to be compatible with the STEP7 topol-
ogy scanner.
ifType(1..3) integer 6 (“Ethernet-
csmacd”)
Type of interface
ifMtu(1..3) integer 1500 Size of largest datagram that can be sent/re-
ceived on the interface, specified in octets
ifSpeed(1..3)
gauge
0 or 100 000 000 Data transfer rate of the Ethernet port in bits
per second. The speed is only shown for
ports where the link status is "up".
ifPhysAddress(1..3) octetstring MAC address for the ports
ifAdminStatus(1..3) integer 1 (“up”) Desired state of the Ethernet port
ifOperStatus(1..3) integer 1 (“up”) or 2 (“down”) Current operating state of the Ethernet port.
(Link = "up", No link = "down".)
ifLastChange(1..3) timeticks Time when state
changed, except
ifLastChange(3) = 0
Time (since start-up) when the port changed
to its current state, see previous variable. In-
dicated in multiples of hundredths of a
second
ifInOctets(1..3)
counter
ifInOctets(1..3) =
Number of octets
Total number of octets received on the inter-
face, including framing characters
ifInUcastPkts(1..3)
counter
ifInUcastPkts(1..3) =
Number of unicast
packets
Number of subnetwork-unicast packets deliv-
ered to a higher-layer protocol
ifInNUcastPkts(1..3)
counter
ifInNUcastPkts(1..3)
= Number of non-uni-
cast packets
Number of non-unicast (i.e. subnetwork-
broadcast or subnetwork-multicast) delivered
to a higher-layer protocol.
ifInDiscards(1..3)
counter
ifInDiscards(1..3) =
number of discarded
packets
Number of inbound packets which were dis-
carded, without any error detected, not to be
delivered to a higher-layer protocol. (One rea-
son to discard packages might be to free up
buffer space)
ifInErrors(1..3)
counter
ifInErrors(1..3) =
number of error
packets
Number of inbound packets with errors
ifInUnknownProtos
(1..3)
counter
ifInUnknownProtos
(1..3) = Number of
unknown packets
Number of packets received via the interface,
discarded because of an unknown or unsup-
ported protocol.
ifOutOctets(1..3)
counter
ifOutOctets(1..3) =
Number of octets
Total number of octets transmitted out from
the interface, including framing characters
ifOutUcastPkts(1..3)
counter
ifOutUcastPkts(1..3)
= Number of unicast
packets
Total number of packets that higher-level pro-
tocols requested to be transmitted to a sub-
network-unicast address, including those that
were discarded or not sent.
ifOutNUcastPkts
(1..3)
counter
ifOutNUcastPkts
(1..3) = Number of
non-unicast packets
Total number of packets that higher-level pro-
tocols requested be transmitted to a non-uni-
cast (i.e. a subnetwork-broadcast or
subnetwork-multicast) address, including
those that were discarded or not sent.
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
