SECTION 8 MAINTAINING YOUR ARMOR X7 PAGE 136
9711-26400-0001
EXPORT CONTROLLED – SEE PAGE 3
Rev -
Table 20. Remove and Replace the Solid State Drive
STEP ACTION
1.
Power down the computer and disconnect any external power.
2.
Place the computer face down on a clean surface and remove 14 Philips screws
from the cooling register/cover then remove the cover.
3.
Lift up on the drive and carefully disconnect it from the computer.
4.
Insert the replacement drive.
5.
Replace the back cover and secure with the 14 Philips screws.
Removing and Replacing the Batteries
Refer to Table 22 and Figure 73 to remove and replace a battery.
CAUTION!
Only one battery at a time can be removed and replaced during
operation without causing loss of data or system shutdown.
Connect external power first before removing both batteries.
NOTE
If your X7 has only one battery pack, install it in the left side
(primary) battery slot.
