Appendix B
Using the X7 External Battery Charger
The X7 battery charger can recharge a single battery in 2.5 hours and two batteries in less than
6 hours. You can remove or insert a battery at any time in the charge cycle without causing
damage to the charging circuits or to the battery.
Table 34. Charging a Battery
Step Action Comment
1.
Hold the battery with its connector
pointing down and the rounded edge of
the battery facing away from the
charger, as shown in Figure 93.
2.
Insert the battery into the bay and gently
press down to engage the locking
latches. Rock the battery slightly to
ensure the battery is locked in place.
The battery button will snap into place
when the latch is engaged. The charging
wil
l begin immediately, as indicated by
the steady yellow charge indicator.
When charging is complete, the yellow
LED will turn off and the green (fully
charged) LED will turn on.
3.
To remove the battery, press on the
spring-
loaded battery release button
and
lift the battery from the charging
bay.
