Working with the Pen Screen
When the pen screen is active, you can steer the cursor and perform many functions by simply
hovering close to the screen without actually touching it. Other functions are initiated by
pressing the tip to the screen surface to activate the tip switch or by pressing the side button
switch (refer to Table 5 for more information).
Yo ur X7 Active Pen
The pen that comes with your X7 (Figure 10) is stored in a slot on the back panel (see Figure 5)
and has circuitry that interacts with the digitizer assembly built into the pen screen. The digitizer
detects the pen tip close to the screen and activates certain functions like steering the cursor or
performing a right click action if the pen is allowed to hover for a few seconds. Pressing the tip
to the screen activates a tip switch that performs a left-click action.
Using the X7 Pen with the Pen Screen
Table 5 lists mouse-type objectives you can perform using the X7 pen with the pen screen.
NOTE
This description assumes the side button is set for the (default)
right-click function.
Table 5. Pen Screen Actions.
MOUSE OBJECTIVE PEN ACTION
Select option or tab or open submenus.
Fill selection boxes.
Activate buttons.
Deselect highlighted objects (touch
next to
the object).
Tap once
Selects multiple objects. Touch pen tip to display and drag box around
objects
Highlight object or option. Hover over object or option
Move object on the desktop. Touch an object and move it with the pen.
Start application or open folder. Tap twice
Highlight option, open menus (right click). Hover tip nea
r screen until option menu
opens
-or-
Press side switch and touch object or option
(see
Pen Tablet Properties Utility for other
side switch options).
