Armor X7 - Figure 40. X7 Rear Compartment

SECTION 4 NETWORKING PAGE 85
9711-26400-0001
EXPORT CONTROLLED – SEE PAGE 3
Rev -
Figure 38. X7 Rear Compartment
STEP ACTION CONDITION OR INDICATION
5.
Place a fingertip in the notch on the left side of
the SIM socket cover and slide the cover to
the right until you feel an indent, then lift up.
6.
Insert the SIM card with the corner notch at
the lower left.
SIM CARD
SOCKET
COVER
REMOVAL
SLOT
