Calibrating the Display in Windows XP
You can access both screen calibration routines through ARMORutils or access the pen screen
calibration through the Pen Tablet Properties utility and the touch screen calibration through
the Touch Settings utility in Control Panel.
Us ing ARMORutils
This capability is not currently available.
Using the Pen Tablet Properties Utility (Pen Screen
Only)
The pen screen should be calibrated using the procedure in Table 30.
Table 29. Calibrate the Pen Screen Using the Pen Tablet Properties Utility
STEP
ACTION CONDITION OR INDICATION
1.
Select Start
à
Control Panel
à
Hardware and Sound
à
Pen Tablet
Properties.
The Pen Tablet Properties dialog window
opens, as shown in Figure 82.
