ASC Delta Rib - Gable Flashing Preparation

20 August 2016
www.ascbp.com
Light Gauge Metal Roof and Wall Panels
Installation Guide for Delta Rib
™
, Delta Rib
™
III, Nor-Clad
®
, Strata Rib
®
& 2½ Corrugated
Gable Flashing Preparation
STEP 1
STEP 2
STEP 3
GABLE
REMOVE THIS MATERIA
L
* SEE TABLE
FOR DIMENSION
GABLE
SNIP HERE
REMOVE THIS MATERIAL
2 1/2"
1 1/2"
1 1/2"
SNIP HERE
1"
1"
GABLE
FOLD 90˚
REMOVE THIS MATERIAL
GABLE
REMOVE THIS MATERIA
L
* SEE TABLE
FOR DIMENSION
GABLE
SNIP HERE
REMOVE THIS MATERIAL
2 1/2"
1 1/2"
1 1/2"
SNIP HERE
1"
1"
GABLE
FOLD 90˚
REMOVE THIS MATERIAL
Roof Pitch Dimension
3:12 2"
4:12 1
7
⁄8"
5:12 1
11
⁄16"
6:12 1
6
⁄16"
12:12
5
⁄8"
Note: Length of uncut
gable must extend 2
1
⁄2"
past eave fascia.
