ASC Delta Rib - Skylight Flashing (Uphill Side)

Light Gauge Metal Roof and Wall Panels Installation • August 2016 33
ASC Building Products
A Division of ASC Profiles LLC
6" MIN
2 1/2"
3 1/2"
12"
BOTTOM POLYETHYLENE CLOSURE
SET IN SEALANT ALL AROUND
ASC'S LIGHT
GAUGE ROOFING
2. #14 WOOD SCREW
@ EACH SIDE OF EACH RIB
OR 8" O.C. FOR CORRUGATED
UPHILL SKYLIGHT (SK16)
SK16
(Uphill)
2 – Skylight Flashing (Uphill Side)
