ASC Delta Rib - Gable Flashing Preparation at Ridge

Light Gauge Metal Roof and Wall Panels Installation • August 2016 21
ASC Building Products
A Division of ASC Profiles LLC
EQUAL
EQUAL
VERTICAL CUT
* SEE TABLE
REMOVE THIS
MATERIAL WITH SNIPS
OR POWER SHEARS
REMOVE THIS
MATERIAL WITH SNIPS
OR POWER SHEARS
RIDGE LINE
14" @ STANDARD RIDGE
17" @ VENTED RIDGE
RIDGE LINE
GABLE
RIVET
GABLE
REMOVE THIS
MATERIAL WITH SNIPS
OR POWER SHEARS
EQUAL
EQUAL
VERTICAL CUT
* SEE TABLE
REMOVE THIS
MATERIAL WITH SNIPS
OR POWER SHEARS
REMOVE THIS
MATERIAL WITH SNIPS
OR POWER SHEARS
RIDGE LINE
14" @ STANDARD RIDGE
17" @ VENTED RIDGE
RIDGE LINE
GABLE
RIVET
GABLE
REMOVE THIS
MATERIAL WITH SNIPS
OR POWER SHEARS
Gable Flashing Preparation at Ridge
STEP 1 STEP 2
STEP 3 STEP 4
Roof Pitch Dimension*
3:12 1
1
⁄16"
3.5:12 1
1
⁄4"
4:12 1
7
⁄16"
5:12 1
3
⁄4"
6:12 2
3
⁄16"
12:12 4
7
⁄16"
* Dimensions only apply to
G4 Gable Flashing
