ASC Delta Rib - Valley Top End; Valley

Light Gauge Metal Roof and Wall Panels Installation • August 2016 41
ASC Building Products
A Division of ASC Profiles LLC
Valley Top End
FIELD MITER AND ASSEMBLE
USE EMSEAL CLOSURE
TO CLOSE OFF VALLEY FLASHING
ASC'S LIGHT
GAUGE ROOFING
ROOFING NAIL
2 ROWS OF BUTYL
MASTIC TAPE
VALLEY (V1)
INSTALL EMSEAL CLOSURES
DIAGONALLY ACROSS THE BOTTOM
SIDE OF THE PANEL AND
SET IN SEALANT ALL AROUND
