TD 92483GB
2008-06-05/ Ver. B
Installation and Operation Manual
UPAC- Unite Packet for Messaging and Alarm
25
• Message Action
Note: Call IDs must be defined in Messaging Users. Refer to 4.1 Add Users on page 12.
1 Enter the Call ID that should receive the message in the Call ID text field.
• Click the “user” symbol to select an already configured Call ID.
• Click the “message” symbol if the message is to be sent as a reply to the sender
of the alarm or data.
2 Enter the message text in the Message Text field. By clicking the symbols to the
right of the text field you can add valuable information to the message, such as call
ID of the sender, type of alarm and the location (location requires UPAC LSP
licence). If an input is activated the description of the input can be added.
Figure 17. Available information for the alarm trigger
Figure 18. Available information for the input trigger
Figure 19. Available information for the data trigger
3 Select number of beeps in the Beep Code drop-down list.
4 Select message priority in the Priority drop-down list.
5 Select the Request confirmation check box if it shall be possible for the user to
accept or reject the message. If no response is received an escalation action can
take place, refer to Select Escalation Action on page 26.
Figure 39.
Figure 40.
Figure 41.
Figure 42.
Figure 43.
