SECTION 2 - Description
Table 1
Package
2.1 Product description
The HMI30 family is the HMI solution with RISC architecture that allows running
Premium HMI3 and Ubiquity software platforms.
Based on ARM Cortex A8 processor and Microsoft Windows Embedded Com-
pact 7 (C7P) operating system, HMI30 is available in BASIC or ADVANCED ver-
sion according to Premium HMI 3 runtime installed.
The systems can have standard (HMI30) or true flat (HMI30-TF) front frame.
2.2 Key features
 CPU ARM CORTEX A8
 Frontal IP 65
 O.S. Microsoft Windows Embedded Compact 7 (C7P) installed on flash
memory.
 Data and programs are contained in two different flash disk devices.
 Asem Premium HMI software.
 Asem Ubiquity software.
2.3 Package
HMI30 package consists of:
HMI30 system
User’s guide CD
Quick Installation guide
n.10 Clamps with grub
screw (depending of the
LCD size)
n.1 Power supply plug
Premium HMI software CD
Ubiquity software CD
