22
SECTION 3 – Installation and connection
Note:
please refer to paragraph 2.3 Package.
3.1 Preparation for installation
3.1.1 Select the mounting location
Points to observe when selecting the mounting location:
a) Position HMI30 to avoid exposure to direct sunlight.
b) Position HMI30 such that it is ergonomically accessible for the operator.
c) Choose a suitable mounting height.
d) Ensure that the ventilation holes are not covered.
3.2 Checking the package contents
Check the package content for visible signs of transport damage and for
completeness.
In the case of damaged parts, contact your ASEM representative. Do not
install parts damaged during shipment.
3.3 Checking the operating conditions
Read carefully the standards, approvals, EMC parameters and technical
specifications for operation of the HMI device. This information is availa-
ble in the following sections:
o Certificates and approvals (see section 8).
o Electromagnetic compatibility (see section 8).
Check the mechanical and climatic ambient conditions for operation of
the HMI device: Ambient conditions (see section 8).
Follow the instructions for local use of the HMI device: Notes about us-
age.
Adhere to the permissible rated voltage and the associated tolerance
range:
o 24V
o Range: 18÷36 V
DC
