ASEM HMI30 - Putting the HMI30 into Operation

11
HMI30 / HMI30-TF User’s guide
Figure 5
Full aluminium front panel detail
Figure 6
Aluminium front panel with
true flat technology detail
2.5 Front view
2.5.1 Full aluminium front panel
Full aluminium front panel
Touchscreen display
2.5.2 Aluminium front panel with True Flat technology
Aluminium front panel with top polyester film
Touchscreen display
1
2
1
2
1
2
1
2
