ASEM HMI30 - (SVGA) Display Characteristics; (XGA) Display Characteristics; Display Characteristics; Table 37 10.4 Display Characteristics

66
SECTION 8 - Technical specifications
Table 37
10.4” display characteristics
Table 38
12.1” (SVGA) display characteristics
Table 39
12.1” (XGA) display characteristics
7.1.4 10.4” display characteristics
10.4” display characteristics
Dimensions
10.4” (4:3)
Technology
TFT active matrix
Display area
158.4 (W) x 211.2 (H) mm
Resolution
800 x 600 pixels
Display color
16.2M colors
Pixel Pitch
0.264 (W) x 0.264 (H) mm
Luminance
400 cd/m
2
Horizontal viewing angle
(left + right)
160
◦
Vertical viewing angle
(up + down)
140
◦
Contrast ratio
700:1 (Typ.)
Response time (Rise)
20 ms (Typ.)
Backlight
LED
7.1.5 12.1” (SVGA) display characteristics
12.1” display characteristics
Dimensions
10.4” (4:3)
Technology
TFT active matrix
Display area
184.5 (W) x 246.0 (H) mm
Resolution
800 x 600 pixels
Display color
16.2M colors
Pixel Pitch
0.264 (W) x 0.264 (H) mm
Luminance
500 cd/m
2
Horizontal viewing angle
(left + right)
160
◦
Vertical viewing angle
(up + down)
140
◦
Contrast ratio
800:1 (Typ.)
Response time (Rise)
4 ms (Typ.)
Backlight
LED
7.1.6 12.1” (XGA) display characteristics
12.1” display characteristics
Dimensions
12.1” (4:3)
Technology
TFT active matrix
Display area
184.32 (W) x 245.76 (H) mm
Resolution
1024 x 768 pixels
Display color
16.2M colors
Pixel Pitch
0.240 (W) x 0.240 (H) mm
Luminance
600 cd/m
2
Horizontal viewing angle
(left + right)
160
◦
Vertical viewing angle
(up + down)
140
◦
Contrast ratio
700:1 (Typ.)
Response time (Rise)
5 ms (Typ.)
Backlight
LED
